Zidoo NEO S
Specifications
- Model
- NEO S
- Display
- 5-inch OLED HD touch screen
- Chassis
- Aviation aluminum alloy
- CPU
- Realtek RTD1619DR ARM Cortex-A55(hexa-core)
- GPU
- ARM Mali-G51 MP3
- Internal SSD
- 256G SSD (M.2 SATA 3.0 2280, up to 1TB)
- Audio DAC
- ESS 9068*2
- Wi-Fi
- 2.4G+5G dual band WiFi, 802.11 a/b/g/n/AC 2T2R MIMO 867Mbps
- Ethernet
- RJ-45(10/100/1000Mbps)
- HDMI Output
- 2.0a (4K@60fps/12Bit/HDR/BT2020/YCbCr 4:4:4 output), Support audio passthrough
- Video Decoding
- 4K@60p HEVC/H.265 12Bit HDR10, HDR10+, Dolby Vision
- Audio Decoding
- Support true-hd HD audio passthrough, stereo PCM decoding, Built-in DAC audio decoding: support up to stereo DSD512, PCM 768KHz 32Bit, MQA
Show all 29 specificationsShow fewer
- Bluetooth Audio Input
- CSR8675 flagship Bluetooth audio module(BT5.0), Support lossless audio protocols such as SBC/AAC/aptX/aptX LL/aptX HD/LDAC
- USB Audio Input
- USB audio compatible system: Windows(7,10), Mac, Android, Support up to stereo DSD512, PCM 768KHz 32Bit, MQA
- Digital Audio Input
- USB DAC IN, AES/EBU input, Coaxial input, Optical input
- Digital Audio Output
- Coaxial output, HDMI output, USB Audio output, Bluetooth output
- Analog Audio Output
- Preamp output: XLR(balanced), RCA, Headphone amplifier output: 4.4mm balanced, 6.3mm single-ended
- Headphone Impedance
- 16-300Ω(low-gain mode: 16-32Ω; high-gain mode: 32-300Ω)
- XLR(balanced) Output
- Output Level(Vrms): 4.1 Vrms, THD+N: -118dB, Noise: 2uVrms, SNR: 120dB(20Hz-20kHz), Frequency Response: ±0.25dB(20Hz-20kHz), Crosstalk: -120dB(1kHz,Fs=44.1kHz), DNR: 119dB
- RCA(single-ended) Output
- Output Level(Vrms): 2.16 Vrms, THD+N: -116dB, Noise: 2.5uVrms, SNR: 119dB(20Hz-20kHz), Frequency Response: ±0.258dB(20Hz-20kHz), Crosstalk: -130dB(1kHz,Fs=44.1kHz), DNR: 118dB
- Headphone 4.4mm Balanced Output(low-gain mode)
- Output Level(Vrms): 2.26Vrms, Output Power/Impedance: 310mW/32Ω, THD+N: -116dB, Noise: 1.7uVrms, SNR: 118dB(20Hz-20kHz), Frequency Response: ±0.25dB(20Hz-20kHz), Crosstalk: -128dB(1kHz,Fs=44.1kHz), DNR: 118dB
- Headphone 4.4mm Balanced Output(high-gain mode)
- Output Level(Vrms): 4.1Vrms, Output Power/Impedance: 110mW/300Ω, THD+N: -118dB, Noise: 3.5uVrms, SNR: 120dB(20Hz-20kHz), Frequency Response: ±0.25dB(20Hz-20kHz), Crosstalk: -130dB(1kHz,Fs=44.1kHz), DNR: 119dB
- Headphone 6.3mm Single-Ended Output(low-gain mode)
- Output Level(Vrms): 1.5Vrms, Output Power/Impedance: 138mW/32Ω, THD+N: -114dB, Noise: 3.2uVrms, SNR: 116dB(20Hz-20kHz), Frequency Response: ±0.25dB(20Hz-20kHz), Crosstalk: -128dB(1kHz,Fs=44.1kHz), DNR: 115dB
- Headphone 6.3mm Single-Ended Output(high-gain mode)
- Output Level(Vrms): 2.7Vrms, Output Power/Impedance: 47mW/300Ω, THD+N: -114dB, Noise: 3.5uVrms, SNR: 118dB(20Hz-20kHz), Frequency Response: ±0.25dB(20Hz-20kHz), Crosstalk: -132dB(1kHz,Fs=44.1kHz), DNR: 118dB
- USB Ports
- USB3.0*2, USB2.0*2
- Control Ports
- IR IN, Bluetooth, TCP/IP control(WOL)
- Power Supply
- AC 110~240V 50/60Hz
- Dimensions
- 213(L)*292(W)*101(H)mm
- Packing List
- Remote control*1, Power cable*1, Antennas*3, Product manual*1
In detail
About the NEO S
- 4K UHD Media Player
- Music Streamer
- AV Media Centre
- Hi-Fi Music & Bluetooth Decoder
- Dolby & DTS Advanced Surround Sudio Formats
- XLR Balanced & RCA Analog Audio Preamp Output
- 5-inch OLED Touch-Screen Display
- Dual Independent Large Toroidal Linear Power Supplies
The NEO S is Zidoo's new high-end audio-visual all-in-one device, and is simultaneously a hi-fi music digital decoder, network audio server, AV streamer, headphone amplifier, and more. NEO S inherits the NEO X's craftsmanship and sports an aluminium thickened chassis and 5-inch OLED touchscreen. Built-in is a 256G SSD, dual ES9068 DACs, dual digital/analog power supply modules and large toroidal transformers.
