606 S3 Stand-Mount Speaker: The Ideal Blend of Size and Performance
The 606 S3 stand-mount speaker brings together the perfect fusion of size and performance. Featuring our groundbreaking Titanium Dome™ tweeter along with the remarkable precision and clarity of our celebrated Continuum™ bass/midrange cone, this speaker stands as a testament to acoustic excellence.
Elevating an Icon
The new 606 S3 builds upon the award-winning legacy of the 606 formula and takes it to new heights. By seamlessly integrating the Continuum cone and Titanium Dome tweeter with enhanced speaker terminals and a subtly modernized design, the 606 S3 becomes an irresistible choice for a wider range of music enthusiasts.
Unveiling Layered, Exquisite Details
Introducing the all-new Titanium Dome tweeter, the 606 S3 delivers unparalleled resolution and insight alongside refined high-frequency reproduction. The outcome? A profoundly accurate and immersive journey into your cherished music.
Unraveling Truly Exceptional Sound
The 606 S3 introduces a new, even more acoustically transparent tweeter grille mesh, initially pioneered for our revered Signature models. In collaboration with the fresh Titanium Dome tweeter, the result is an unrivaled level of resolution and realism.
Precision and Transparency at the Forefront
Thanks to its composite construction, the Continuum cone avoids the abrupt transitions in behavior that can hinder the performance of conventional drive units. Immerse yourself in a heightened, neutral performance with the 606 S3, experiencing vocals and instruments with precision and transparency.
Elevated Speaker Terminals
Derived from the speaker terminals introduced in our esteemed 700 Series range, the speaker terminals on the new 606 S3 boast an improved layout, ensuring a cleaner signal path between your amplifier and your loudspeakers.
Size & Weight:
Dimensions: Height: 344 mm (13.6 in) cabinet only, Width: 189 mm (7.4 in) cabinet only, Depth: 300 mm (11.8 in) cabinet only, 328 mm (12.9 in) including grille and terminals
Net Weight: 7.05 kg (15.5 lb)
Technical Features: Decoupled Double Dome Titanium tweeter, Continuum™ cone bass/midrange, Flowport™
Frequency Response: 52Hz - 28kHz ±3dB (reference axis)
Description: 2-way vented-box system
Drive Units: 1x ø25mm (1 in) Titanium Dome high-frequency, 1x ø165mm (6.5 in) Continuum cone bass/midrange
Frequency Range: -6dB 40Hz - 33kHz
Sensitivity: 88dB (on axis at 2.83Vrms at 1m)
Harmonic Distortion: 2nd and 3rd harmonics (90dB, 1m on axis), <1% 100Hz - 22kHz, <0.5% 150Hz - 12kHz
Nominal Impedance: 8Ω (minimum 3.7Ω)
Recommended Amplifier Power: 30W - 120W into 8Ω on unclipped programme
Max Recommended Cable Impedance: 0.1Ω
