Trinnov AltitudeCI – Scalable Immersive Audio for Custom Integration
The Trinnov AltitudeCI brings Trinnov’s exclusive active acoustics technologies to the world of custom integration, with native DanteⓇ and AES67 support, a scalable channel count, and a future-proof network architecture designed for the most demanding residential and professional environments.
Built for Scalable, Networked Integration
-
Dual AoIP Support – AltitudeCI supports both AES67 and DanteⓇ natively, combining the precision of DCI and pro audio standards with Dante’s plug-and-play simplicity. Directly connect to digital amplifiers like the Amplitude16 for a seamless all-digital workflow.
-
Three Ethernet Ports, Fibre-Ready – Featuring one RJ45 port and two SFP cages (fibre or copper), AltitudeCI adapts to any network. Configurable for redundant AoIP streams, segregated networks, or integrated switch mode.
-
Scalable Channel Count – Available from 8 to 32 outputs (in 2-channel increments). A 64-channel build-to-order version will launch in 2026 for large-scale, DCI-grade private cinemas and pro audio applications.
Flexible Outputs for Any System
-
8 Balanced Analogue Outputs – Ideal for Hi-Fi or compact theatre systems.
-
Up to 32 AES/EBU Digital Channels – Input and output, no extra cards required.
-
Native AoIP Routing – Fully compatible with DanteⓇ and AES67.
-
Hybrid Systems Made Easy – Build combinations of analogue, digital, and networked outputs without external converters.
The integrated flexible routing matrix eliminates the need for optional I/O cards or external hardware — simplifying installation and maximising reliability.
Tailored Configurations for Every Project
Whether you are designing a high-end stereo system, a private media room, or a multi-row cinema with 30+ speakers, AltitudeCI scales to fit your needs.
High-End Stereo & Surround (AltitudeCI-8)
-
Perfect for Hi-Fi users, 2.0 with multiple subwoofers, or 7.1 setups.
-
Full Trinnov performance with WaveForming™ and active crossovers.
-
Upgrade channels via software without additional hardware.
First Step into Immersive (AltitudeCI-12)
-
Supports 5.4.2, 7.1.4, and 7.4 layouts.
-
Ideal for media rooms and compact cinemas.
-
Full-format decoding with hybrid outputs.
-
Cost-effective with the Amplitude16 (Dante input board).
Serious Home Theatre (AltitudeCI-16 & CI-20)
-
For 9.4.6, 11.4.4, and 9.6.4 layouts.
-
Full rendering of overhead objects with multi-subwoofer WaveForming™.
-
Compact 2RU form factor.
-
Scalable with Amplitude16 amplifiers.
Extreme Configurability (AltitudeCI-20 to CI-32)
-
From 13.4.6 to 11.6.8 and beyond.
-
Up to 32 discrete outputs with hybrid analogue + AoIP routing.
-
Designed for reference-level private cinemas.
-
Supports complex layouts, multi-row coverage, and advanced bass arrays.
DCI-Grade & Professional Cinemas (AltitudeCI-64)
-
Scales to 64 channels for post-production, screening rooms, and DCI-grade installations.
-
Native AES67 integration with DCI servers.
-
Handles both professional and consumer playback.
-
Trusted by top studios and luxury cinemas worldwide.
| Category | Details |
|---|---|
| Audio Processing | • Channel Count: Available from 8 to 32 outputs • Future Option (2026): Up to 64 channels (build-to-order) • Architecture: Software-based, 64-bit floating point processing • Sample Rate: Up to 192kHz (channel dependent) |
| Immersive Audio Formats | • Decoded Formats: Dolby Atmos, DTS:X Pro, Auro-3D, IMAX Enhanced • Upmixers: Dolby Surround, DTS Neural:X, Auro-Matic • Flexibility: Full-format decoding with channel-to-speaker assignment |
| HDMI Connectivity | • Inputs / Outputs: 4 × HDMI Inputs, 2 × HDMI Outputs • Version: HDMI 2.1 with HDCP 2.3 • Max Bandwidth: 40 Gbps on all inputs and outputs • 8K Support: Up to 8K60 (4:2:0 chroma only) • 4K Support: Up to 4K120 (with full 4:4:4 chroma) • Chroma Subsampling: 4:4:4, 4:2:2, 4:2:0 (format-dependent) • HDR Support: HDR10, HDR10+, Dolby Vision, HLG • Gaming Features: VRR, FRL, ALLM • Other Features: On-screen display (OSD), full pass-through |
| Audio Inputs | • Dante: Up to 32 input channels • Ravenna / AES67: Up to 32 input channels (48kHz) • AES/EBU: Up to 32 inputs via 2 × DB25 • S/PDIF: 1 × coaxial + 1 × optical • 3D Microphone: 1 × Ethercon input (with power) • Independence: All inputs independent • Future AoIP Input Capacity (2026): Up to 64 inputs (build-to-order) |
| Audio Outputs | • Dante: Up to 32 output channels • Ravenna / AES67: Up to 32 output channels (48kHz) • AES/EBU: Up to 32 outputs via 2 × DB25 • Analogue: 8 × balanced outputs via 1 × DB25 • Analogue Output Level: +18 dBu max • THD+N (analogue output): 110 dB (1kHz 0dBFS, 20kHz BW) • Dynamic Range (analogue output): 115 dB A-weighted (ref +18dBu) • Channel Assignment: Any output channel to any physical output • Output Types: Analogue, digital or AoIP |
| Network Architecture & AoIP | • AoIP Support: Native Dante (hardware), Ravenna/AES67 (software) • Compatibility with Dolby media servers: via AES67 • Ethernet Ports: 3 × Gigabit (1 × RJ45, 2 × SFP cages) • SFP Module: 1 × RJ45 provided • Networking Modes: Integrated switch, isolated, or redundant paths • AoIP Simplification: DirectLink supported with Amplitude16 |
| Control & Integration | • Full UI Access: macOS/Windows app, Web UI • Mobile Remote: iOS & Android app • Control Drivers: Crestron, Control4, Savant, RTI, AMX, Nice, AVA • Physical Control: IR input (3.5 mm jack, receiver included), RS-232 • Triggers: 1 × input, 4 × programmable outputs • IR Remote Control: Optional • Remote Management: Partner access via my.trinnov.audio • Front Panel: 5-inch touchscreen • Power Modes: Standby & fast boot (firmware-ready) |
| Digital Acoustic Optimisation | • Trinnov Technologies: Optimizer, WaveForming & Remapping • Calibration Workflow: Step-by-step guided setup • 3D Mic Integration: Automatic compensation file upload |
| Audio Streaming | • Roon: Certified Roon Ready endpoint (soon) • Audirvãna: Certified (soon) • UPnP: FLAC, WAV, MP3, OGG |
| Power & Thermal | • Power Supply: 100–240 V auto-switching • Max Consumption: 140 W (0.5 W idle) • Cooling: Temperature-controlled exhaust fans • Heat Output: 480 BTU/hr (max load) • Mains Fuse: 2 × T800mA |
| Chassis & Dimensions | • Form Factor: 2RU rack-mountable • Net Weight: 8.6 kg / 19 lbs • Front Plate: Smoked-glass touchscreen in brushed aluminium • Design: Minimalist, with removable ears/feet • W × H × D (no ears/feet): 438 × 88 × 371 mm / 17.24 × 3.46 × 14.61 in • W × H × D (with ears/feet): 482 × 97 × 371 mm / 18.98 × 3.82 × 14.61 in |
